Plastic construction site power distributor 63A (10kA), type 570KS-MH-14, 2xT25,6xT23,2xCEE16/5,2xCEE32/5,1xCEE63/5

Name: Plastic construction site power distributor 63A (10kA), type 570KS-MH-14, 2xT25,6xT23,2xCEE16/5,2xCEE32/5,1xCEE63/5
Brand: Normrahmen AG
SKU: 77305
Price: 470.29 CHF
Availability: InStock

CHF 470.29

Price for: 1 Piece

Prices incl. VAT plus shipping costs

Piece

In Stock
Delivered Tomorrow

Stock Availability

13 Piece Still in Stock

In Procurement

Available Between Wed 04.11 and Fri 06.11

30 Piece Ordered from Manufacturer

Unit: 1 Piece

Prod. No: 77305

EAN: 8693151701715

Item number: 77305

EAN: 8693151701715

Order for more CHF 79.00 and you will receive your order free of shipping costs.

Your advantages with Normrahmen AG

Free shipping from 79 CHFwithin Switzerland

Production & Developmenthigh quality products

Everything from a single source60 day return policy

Attractive cost advantagesthanks to our own production

Product information "Plastic construction site power distributor 63A (10kA), type 570KS-MH-14, 2xT25,6xT23,2xCEE16/5,2xCEE32/5,1xCEE63/5"

Plastic site power distributor 570KS-MH-14 63A (10kA)

Our plastic power distribution boards are very practical thanks to their compact and lightweight design. The plastic material is environmentally friendly and resistant to chemicals. Compliance with all current regulations and standards (IEC EN-61439). The distributors can also be configured according to your individual requirements.

Corrosion-free, UV-resistant, oil and acid-resistant, very good chemical resistance, light grey Ral 7035, IP44, completely ready for connection, recorded design certificates and parts certificates in accordance with IEC EN 61439-4

Features of plastic site power distribution board 390KS-MH-10 63A (10kA):

With handle
Direct wall mounting possible
Dimensions (L x W x D): 570 x 380 x 240mm
1 x RCD 63A type A 3PN 30mA
2 x LS 32A C 3P 10kAkA
1 x LS 16A C 3P 10kA
1 x FI 40A Type A 3PN 30mA
1 x LS 16A C 3P 10kA
3 x LS 16A C 1P 10kA
2 x socket outlet T25 16A 230/400V IP55
6 x socket outlet T23 16A 230V IP55
2 x socket outlet CEE 16A 5P 400V 6h IP44
2 x socket outlet CEE 32A 5P 400V 6h IP44
1 x socket outlet CEE 63A 5P 400V 6h IP67
1 x 2.5 metre PUR cable 5x10mm2 with CEE 63A 5P 6h 400V plug
Preparation for 2x cable gland M25 or M32
All contacts of the sockets are nickel-plated

Optionally available:

Base frames available for mobile use

Item number:	77305
Characteristic:	C
Clock position:	6h
Contacts:	nickel-plated
ETIM class:	EC000484
Feed-in:	CEE 63A 5P 6h 400V
Frequency:	50 & 60 Hz
Halogen-free:	Yes
Number of modules:	26

Number of sockets:	13
Protection class:	IP 44, IP55
Rated current:	63A
Rated voltage:	230/400V
Residual current type:	A
Short-circuit resistance:	10kA
With connection cable:	Yes
