Product information "Energy meter EMU Professional II 3/100, M-Bus, MID B+D approval, 100A direct measurement 3PN"

The EMU Professional 3/100 M-Bus 3-phase bidirectional meter for DIN rail mounting has four S0 pulse outputs and is suitable for energy management in accordance with ISO 50001 as well as for energy cost billing.

• Top-hat rail three-phase electricity meter for direct connection

• Bidirectional meter

• 4x S0 pulse outputs (active energy supplied, active energy consumed, reactive energy)

• MID B+D approval for energy cost billing

• Suitable for energy management in accordance with ISO 50001

• 2-tariff (day / night), tariff switching via 230V signal

• Graphical display for easy reading and configuration

Key technical specifications: Top-hat rail three-phase electricity meter, bidirectional meter for supply and consumption 3x230/400V, 5(100)A, 50 Hz, accuracy class B (1%) Direct connection up to 100A, mounting width: 5 TE (90mm) Backlit graphical LCD 38x28mm (WxH) MID B+D ex-works for billing purposes Retrievable measurement values (display + M-Bus interface): Active energy consumption: kWh total, Tariff 1, Tariff 2; Active energy supplied: kWh total, Tariff 1, Tariff 2; Reactive energy: kvarh total, Tariff 1, Tariff 2; Voltage L1 / L2 / L3; Current total and per phase L1 / L2 / L3 Active power total + and per phase L1 / L2 / L3 Reactive power total + and per phase L1 / L2 / L3 Apparent power total + and per phase L1 / L2 / L3 CosPhi L1 / L2 / L3 Mains frequency Hz Configuration: S0 pulse rate and time, e.g. 1 / 10 / 100 / 1000 / 10,000 pulses per kWh, configurable via buttons

Metas – Certified

Item number: 60701
Manufacturer number: P20A000M
Bidirectional counter: Yes
Blockchain technology: Optional
Calibrated: Yes
ETIM class: EC001506
Energy type: Active energy supply, active energy purchase & Reactive energy
Execution of the interface: M-BUS
Illuminated display: Yes
MID: MID B+D
Maximum current (Imax): 100A
Measurement type: Direct measurement
Meter type: Electronic
Mounting type: REG (top-hat rail)
Permitted for billing purposes: Yes
Polar type: Four-wire
Pulse outputs: 4
Pulse type: S0
Suitable for energy management in accordance with ISO 50001: Yes
Tariff execution: Double tariff
Width in pitch units: 5 Module
