Product information "QS NH switch-disconnector strip with fuses size 2, 185mm, AU-M12, operator-independent switching"

QUADRON®185Power Speed without CrossLink contacts (busbar terminals must be ordered separately: “69734”) When the cover is open, all accessible parts are de-energised Operator-independent switching (switching without protective equipment) Cover lockable with a double-bit lock Mixed configuration with all 185 Power components Can be sealed in both the on and off positions When switched off, can be locked with up to 3 padlocks The use of isolating switches is not authorised. The rated values specified in this product description apply exclusively to the use of fuses.
Item number: 69720
Manufacturer’s number: 33632
Cable connection: Flat connection M12
Conditional rated short-circuit current Icc: 120kA (AC500V)
Connection technology: Screw connection
ETIM class: EC001046
Electronic fuse monitoring (ESÜ): No
Frequency: 50 & 60 Hz
Halogen-free: Yes
Max. Rated operating current Ie: 400A
Max. Rated operating voltage Ue: 800V
Mounting type: 185mm system
Number of poles: 3
Number of wiring points: 6
Rated impulse voltage: 12kV
Rated insulation voltage: 1000V AC, 1000V DC
Rated voltage: 690V AC, 800V DC
Size: NH2
Suitable for transformer installation: No
Switchability: 3-pole switchable
Top or bottom outlet: below
With integrated feed-in connection: No
