Product information "Janitza Modular Expandable Network Analyser UMG 96-PQ-L"

The UMG 96-PQ-L has expanded the 96 series with a whole range of useful functions. This modular power analyser boasts a large memory capacity which, thanks to a special data compression technique, offers up to 15 years of storage. The memory allocation ensures that the long storage period for current, power and work is maintained even during high-resolution power quality measurements. Your data is therefore safe.

Whether for temperature monitoring, voltage quality analysis or residual current monitoring, the UMG 96-PQ-L offers the right functions for all applications and, thanks to EMC Class B compliance, can be used in the immediate vicinity of residential, commercial and industrial areas. All values can be viewed conveniently and easily via the colour graphic display. In addition, the UMG 96-PQ-L offers the option of using plug-in modules that extend its range of functions.

Item number: 66541
Manufacturer’s number: J.52.36.001
4th current transformer input: Only with additional module
Accuracy A: 0.2%
Accuracy V: 0.2%
Active energy class: 0.2S (.../5 A)
Analogue output: 1
Asymmetry: No
Clock: Yes
Current measuring channels: 3 / with additional module 4
Digital / pulse output: 3
Digital inputs: 3
Distortion factor THD-U / THD-I in %: Yes
ETIM class: EC002301
Execution of the interface: Modbus RTU RS485, with additional module 1x TCP/IP (Ethernet / network)
Fault recorder function: No
Harmonics V/A: 1.-65.
Integrated logic: Comparator
Memory min / max values: Yes
Memory size: 64 MB
Quadrants: 4
Residual current inputs: None / with additional module 2
Sampling frequency 50/60 Hz: 13.67 kHz
Short-term interruptions: No
Short / long-term flicker: No
Supply voltage: 90 - 265V AC & 90 - 250V DC
Temperature input: None / with additional module 1
Web server / e-mail: No
