Janitza (ALL-IN-ONE) Modular Expandable Network Analyser UMG 801

Name: Janitza (ALL-IN-ONE) Modular Expandable Network Analyser UMG 801
SKU: 66576
Price: 2293.88 CHF
Availability: LimitedAvailability

CHF 2,293.88

Price for: 1 Piece

Prices incl. VAT plus shipping costs

Accessories for the Janitza (ALL-IN-ONE) Modular Expandable Power Analyser UMG 801

pcs.

Janitza module for extending the UMG 801, module 800-CT8-A

CHF 717.03

pcs.

Janitza module for extending the UMG 801, transfer module set 800-CON

CHF 315.71

pcs.

Janitza RD 96 Remote Display for UMG 801

CHF 524.39

Piece

Clearance
Delivered Tomorrow

Stock Availability

1 Piece Still in Stock

While Supplies Last

This item is being cleared out and will not be restocked.

Unit: 1 Piece

Prod. No: 66576

EAN: 4251861100286

Item number: 66576

Manufacturer number: J.52.31.001

EAN: 4251861100286

Order for more CHF 79.00 and you will receive your order free of shipping costs.

Your advantages with Normrahmen AG

Free shipping from 79 CHFwithin Switzerland

Production & Developmenthigh quality products

Everything from a single source60 day return policy

Attractive cost advantagesthanks to our own production

Product information "Janitza (ALL-IN-ONE) Modular Expandable Network Analyser UMG 801"

The UMG 801 offers various communication interfaces and enables direct data transmission via OPC UA to higher-level systems. The RD 96 extension adds operating convenience and additional safety to the control cabinet.

Item number:	66576
Manufacturer number:	J.52.31.001
4th current transformer input:	Yes
Accuracy A:	0.2%
Accuracy V:	0.2%
Active energy class:	0.2S (.../5 A)
Analogue output:	1
Asymmetry:	Yes
Clock:	Yes
Current measuring channels:	8
Digital / pulse output:	4
Digital inputs:	4
Distortion factor THD-U / THD-I in %:	Yes
Execution of the interface:	Modbus RTU RS485, TCP/IP (Ethernet / Network , USB
Fault recorder function:	No

Harmonics V/A:	1.-63., 1.-127.
Integrated logic:	No
Memory min / max values:	Yes
Memory size:	4 GB
Quadrants:	4
Residual current inputs:	4
Sampling frequency 50/60 Hz:	25.6kHz (A), 51.2 kHz (V)
Short-term interruptions:	No
Short / long-term flicker:	No
Supply voltage:	24 - 48 V DC, PELV
Temperature input:	4
Web server / e-mail:	No
