TELE, mains and system protection, multinational, M64, frequency and voltage monitoring (NA protection)
Mains and system protection NA003-M64
The reliable NA003-M64 grid and system protection (NA protection) from TELE Haase combines all standards in one device and can therefore be used universally. When operating alternative power generation, NA protection is required by law and disconnects the power generation system (photovoltaic, generator, battery buffer) from the grid in the event of a grid failure. This ensures the safety of the distribution grid, systems and people.
In the event of a defined grid fault, the grid and system protection (NA protection) disconnects the power generation systems (photovoltaic, generator, battery buffer) from the grid. Its function is very important for the reliable protection of the electricity grid and the energy generation systems because it ensures that the connection of an energy generation system does not impair the function or safety of the distribution grid.
Function:
- Protective relay that measures the mains voltage and frequency, contains the actual protective functions and generates the signal for disconnection from the mains
- 1-2 tie switches that ensure the actual disconnection from the grid
To ensure high availability of the supply grid, short-term grid faults must not disconnect the generator from the grid. This "Fault Ride Through" (FRT) refers in particular to short-term undervoltages and overvoltages. Depending on the type and output of the energy generator, different requirements also apply here, which can be adapted via parameterisation in NA003-M64.
Advantages:
- One device for the local & international market
- Easy handling for service personnel & Commissioning engineers
- Preconfigured parameter sets for various countries in Europe & worldwide
- Customised solutions can be implemented thanks to a wide range of configuration options
- FRT (Fault Ride Through) integrated
- Replaces older devices without changes to the control cabinet thanks to design & Availability of older certificates
| Connection cross-section (flexible): | 1.0-2.5 mm2 |
|---|---|
| Connection technology: | Screw terminal |
| Current measuring channels: | 3 |
| Degree of soiling: | 2 |
| Digital inputs: | 2 |
| Frequency: | 50 & 60 Hz |
| Operating temperature from: | -25 °C |
| Operating temperature up to: | 65 °C |
| Protection class: | IP 20 |
| Supply voltage: | 90 - 230V AC & 24V DC |
| Width: | 106.5 mm |
| Width in pitch units: | 6 Module |
