Surge arrester type 1+2+3, ETITEC VS T123 255/25 4+0 RC leakage current-free, (TN-S)
Delivered Tomorrow
Stock Availability
19 Piece Still in Stock
Product information "Surge arrester type 1+2+3, ETITEC VS T123 255/25 4+0 RC leakage current-free, (TN-S)"
Leakage capacity per pole: Iimp= 25 kA (10/350 µs)
Safe disconnecting device
Saves energy costs Does not generate any (mains) follow current Operational and leakage current-free
VDE-AR-N 4100 compliant "Use of type 1 surge protective devices (SPD) in main power supply systems"
Energy-coordinated
Remote signalling as standard
Complies with the IEC 61643-11 and EN 61643-11 standards
| Item number: | 64370 |
|---|---|
| Manufacturer number: | 002442935 |
| Applied technology: | MOV & GDT |
| I imp (10/350) Maximum pulse current: | 100kA |
| I imp (10/350) Pulse current: | 25kA |
| I max (8/20): | 70kA |
| In (8/20): | 30kA |
| Integrated back-up fuse: | No |
| Interchangeable surge modules: | No |
| Leakage current free: | Yes |
| Net shape: | TN-S |
|---|---|
| No back-up fuse required until: | 315A |
| Number of modules: | 8 |
| Type: | T1, T2 & T3 |
| Uc Continuous operating voltage: | 255V |
| Uoc (1.2/50 - 8/20) Overvoltage peak: | 20kV |
| Up - Voltage protection level: | < 1.5kV |
| With remote signalling contact: | Yes |
