NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)
Item number:
65089
Manufacturer number:
001690874
EAN:
3838895822868
Your advantages with Normrahmen AG
Free shipping from 79 CHFwithin Switzerland
Production & Developmenthigh quality products
Everything from a single source60 day return policy
Attractive cost advantagesthanks to our own production
Product information "NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)"
NH fuse switch-disconnector KVL-3 3p M10-M10 to EN60947-3, size NH3 - 630A, 3-pole for mounting on mounting plate with M10 x 25 screw connection
Cable connection at top and bottom
New design (light grey switch cover)
| Cable connection: | Flat connection M10 |
|---|---|
| Conditional rated short-circuit current Icc: | 120kA (AC500V) |
| Max. Rated operating current Ie: | 630A |
| Max. Rated operating voltage Ue: | 690V |
| Mounting type: | Surface mounting |
| Number of poles: | 3 |
| Size: | NH3 |
| Switchability: | 3-pole switchable |
Tab 1 headline "NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)"
Tab 2 headline "NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)"
Tab 3 headline "NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)"
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
Accessories for NH fuse switch-disconnector size 3, 3P, max. 630A, KVL-3 M10-M10 (surface mounting)
Cover plate BLA-KETO-123 VE10, for KETO size 1, 2 & 3 Mounting top, bottom, right or left
4.27 CHF
Price per Piece
Prod-Nr.:
67808
PU:
1
pcs.
Switching position indicator EV-KETO-123, for signalling the switching status for KETO/KVL sizes 1-3
11.18 CHF
Price per Piece
Prod-Nr.:
67877
PU:
1
pcs.
