NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)
Item number:
65086
Manufacturer number:
001690871
EAN:
3838895822837
Your advantages with Normrahmen AG
Free shipping from 79 CHFwithin Switzerland
Production & Developmenthigh quality products
Everything from a single source60 day return policy
Attractive cost advantagesthanks to our own production
Product information "NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)"
NH fuse switch-disconnector KVL-00 3p BC95-BC95 to EN60947-3, size NH00 - 160A, 3-pole for mounting on mounting plate with frame terminal R95, max. clamping range: 1.5-95 Al/Cu (Al 95: max. 125A)
Cable connection at top and bottom
New design (light grey switch cover)
| Cable connection: | Frame terminal R95 1.5-95mm² |
|---|---|
| Conditional rated short-circuit current Icc: | 120kA (AC500V) |
| Max. Rated operating current Ie: | 160A |
| Max. Rated operating voltage Ue: | 690V |
| Mounting type: | Surface mounting |
| Number of poles: | 3 |
| Size: | NH00 |
| Switchability: | 3-pole switchable |
Tab 1 headline "NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)"
Tab 2 headline "NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)"
Tab 3 headline "NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)"
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
Accessories for NH fuse switch-disconnector size 00, 3P, max. 160A, KVL-00 R95-R95 (surface mounting)
Top-hat rail kit Z KETO size 00 100-150 mm, For mounting on 2 top-hat rails for KETO/KVL size 00
12.91 CHF
Price per Piece
Prod-Nr.:
67867
PU:
1
pcs.
Connection compartment cover AA-KETO-00-3/36 VE2, also for height adjustment to KETO 000-3, bottom mounting
5.08 CHF
Price per Piece
Prod-Nr.:
67849
PU:
2
pcs.
Connection compartment cover AA-KETO-00-3/66 VE2, also for height adjustment to KETO 000-3, top mounting
5.89 CHF
Price per Piece
Prod-Nr.:
67860
PU:
2
pcs.
Side panel support BLA-KETO-00-SRL VE10, side mounting right and/or left
3.83 CHF
Price per Piece
Prod-Nr.:
67865
PU:
10
pcs.
Top/bottom panel support BLA-KETO-00-OU VE10, for KETO size 00 Top and/or bottom mounting
1.94 CHF
Price per Piece
Prod-Nr.:
67864
PU:
10
pcs.
Switching position indicator EV-KETO-00/3, for signalling the switching status for KETO/KVL size 00
7.18 CHF
Price per Piece
Prod-Nr.:
67830
PU:
1
pcs.
