Janitza certified power quality analyser (Class A according to IEC 61000-4-30) UMG 512-PRO
In Stock
Delivered the Day After Tomorrow
Delivered the Day After Tomorrow
3
Stock Availability
3 Piece Still in Stock
Item number:
66567
Manufacturer number:
J.52.17.011
EAN:
4251861100262
Your advantages with Normrahmen AG
Free shipping from 79 CHFwithin Switzerland
Production & Developmenthigh quality products
Everything from a single source60 day return policy
Attractive cost advantagesthanks to our own production
Product information "Janitza certified power quality analyser (Class A according to IEC 61000-4-30) UMG 512-PRO"
The UMG 512-PRO power quality analyser (class A) measures all power quality parameters (e.g. OS up to 63rd, flicker, short interruptions, etc.) and also serves as a residual current monitoring device. In contrast to the UMG 511, it has a temperature input. The device is based on the current standards, e.g. EN 50160, IEEE519 or EN 61000-2-4. It also has a 256 MB measurement data memory and can be graphically programmed with Jasic (PLC functionality). Network interfaces and the open communication architecture with numerous protocols (Modbus, IP) enable simple integration into higher-level systems. The UMG 512-PRO has two digital inputs and two digital outputs.
| Item number: | 66567 |
|---|---|
| Manufacturer number: | J.52.17.011 |
| 4th current transformer input: | Yes |
| Accuracy A: | 0.1% |
| Accuracy V: | 0.1% |
| Active energy class: | 0.2S (.../5 A) |
| Analogue output: | None |
| Asymmetry: | Yes |
| Clock: | Yes |
| Current measuring channels: | 4 |
| Digital / pulse output: | 2 |
| Digital inputs: | 2 |
| Distortion factor THD-U / THD-I in %: | Yes |
| Execution of the interface: | Modbus RTU RS232, Modbus RTU RS485, Profibus DP VO , TCP/IP (Ethernet / network) |
| Fault recorder function: | Yes |
| Harmonics V/A: | 1.-63. |
|---|---|
| Integrated logic: | Jasic (7 prg.) |
| Memory min / max values: | Yes |
| Memory size: | 256 MB |
| Quadrants: | 4 |
| Residual current inputs: | 2 |
| Sampling frequency 50/60 Hz: | 25.6 kHz |
| Short-term interruptions: | Yes |
| Short / long-term flicker: | No |
| Supply voltage: | 90 - 265V AC & 90 - 250V DC |
| Temperature input: | 1 |
| Transients: | > 39 µs |
| Web server / e-mail: | Yes |
