Built-in socket outlet T25 16A 5P, IP55, 3PNE 400/230V, nickel-plated contacts, screw connection, SN 441011
In Stock
Delivered Tomorrow
Delivered Tomorrow
99+
Stock Availability
More than 100 Piece in Stock
Item number:
75361
EAN:
8693151695793
Your advantages with Normrahmen AG
Free shipping from 79 CHFwithin Switzerland
Production & Developmenthigh quality products
Everything from a single source60 day return policy
Attractive cost advantagesthanks to our own production
Product information "Built-in socket outlet T25 16A 5P, IP55, 3PNE 400/230V, nickel-plated contacts, screw connection, SN 441011"
Our built-in socket outlets meet the high requirements of the Swiss SN 441011 series of standards and are ideal for equipping new distribution boards or for replacing old built-in socket outlets in existing distribution boards.
| Item number: | 75361 |
|---|---|
| Connection cross-section (flexible): | 1.0-2.5 mm2 |
| Connection cross-section (rigid): | 1.0-4.0 mm2 |
| Connection technology: | Screw terminal |
| Connection type: | Screw connection |
| Contacts: | nickel-plated |
| Flange height: | 49 mm |
| Flange width: | 49 mm |
| Frequency: | 50 & 60 Hz |
| Halogen-free: | Yes |
| Identification colour: | red |
|---|---|
| Insertion direction: | straight |
| Number of poles: | 5 |
| Number of wiring points: | 5 |
| Pole conductor connection depth max.: | 8 mm |
| Protection class: | IP 55 |
| Rated current: | 16A |
| Rated voltage: | 230/400V |
